| Product Name |
LOAD
|
| FrequencyRange (MHz) |
DC-3000MHz
|
| Return Loss(dB) |
≥19
|
| VSWR(dB) |
≤ 1.25
|
| PIM3(dBm) |
≤ -110 dBc (with 2 x 43dBm)
|
| Maximum Input (W) |
100 W
|
| Operating temperature(℃) |
-25℃ to +70℃
|
| Relative humidity(℃) |
0 ~ 95 %
|
| Impedance（Ω） |
50 Ω
|
| Size（mm） |
110 x 80 x 50 mm
|
| Weight(g) |
1500 g
|
| Connector Type |
DIN-M
|
| Ingress protection |
IP65
|
| Color |
Black
|
| ROHS |
Meet
|
